ASME SA515 GR 60 Carbon Steel Plate Boiler And Pressure Vessel SA516 Grade 60 Temperature Range

Name: ASME SA515 GR 60 Carbon Steel Plate Boiler And Pressure Vessel SA516 Grade 60 Temperature Range
Brand: MITTEL
Price: 785 USD

ASME SA515 GR 60 Carbon Steel Plate Boiler And Pressure Vessel SA516 Grade 60 Temperature Range Manufactures

Brand Name : MITTEL

Model Number : SA515 GR 60

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 2Tons

Price : 785 USD/Ton

Payment Terms : L/C, T/T

Supply Ability : 500Tons

Delivery Time : 14 days

Packaging Details : Export Packing

Width : 1000-3500mm

Length : 2000-12000mm

Thickness : 3-200mm

Condition : Hot Rolled

Steel Grade : SA515 GR 60 (415), SA515 GR 65 (450), SA515 GR 70 (485)

Use : High Temperature Pressure Vessels

Contact Now

ASME SA515 Grade 60 is a kind of steel plates material used to fabric middle or high temperature pressure vessels. ASME SA515 Grade 60 has several equivalent material like GB 713 20g,JIS G3103 SB410,DIN 1715 1.0425 . ASME SA515 has three levels ;SA515 GR 60 (415), SA515 GR 65 (450)SA515 GR 70 (485) .

Standard: ASME SA515/SA515M
Steel Grade : SA515 GR 60 (415), SA515 GR 65 (450), SA515 GR 70 (485)
Thickness :3mm -500mm
Width :1000mm-4000mm
Length :1000mm-18000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .

Supplementary Technology:

ASME SA515 Grade 60 steel equivalent material :

China	Japanese	Germany	France	Italy	Sweden	UK
GB 713 20g	JIS G3103 SB410	DIN 1715 1.0425	A48 CP,AP,FP	Fe 460-2-KW	SS21,02,01	Gr 360,400

ASME SA515 Grade 60 steel chemical composition

Composition		Grade 60(415)
C ≤	≤25 ＞25~50 ＞50~100 ＞100~200 ＞200	0.24
		0.27
		0.29
		0.31
		0.31
Mn ≤	Heat analyse	0.90
	Product analyse	0.98
P ≤		0.035
S ≤		0.035
Si	Heat analyse	0.15~0.40
	Product analyse	0.13~0.45

ASME SA515 Grade 60 Mechanical Property

Grade
Grade	Thickness	Yield	Tensile	Elongation
SA515 Grade 60	mm	Min Mpa	Mpa	Min
	200	220	415-550	21
	50	220	415-550	25

MITTEL is a professional ASME SA515 and ASTM A515 steel stockist and supplier. We can supply different product type and grades of ASME SA515. If you have any need of ASME SA515 steel please do not hesitate to contact us .
