GH2132 Incoloy A-286 /S66286 Round Bar
GH2132 Alloy is Fe - ni - cr 15 25 based high temperature alloy, molybdenum, titanium, aluminum, vanadium and trace boron composite reinforcement. Under 650 has high yield strength and lasting and creep strength, and has good processing plastic and satisfactory welding performance. Suitable for manufacturing in the long-term work of aircraft engine under 650 high temperature bearing parts, such as turbine disc, disc, rotor blades and fasteners, etc. The alloy can produce all kinds of shape deformation products such as: plate, forgings, plate, bar, wire and circular pieces, etc.
GH2132 alloy chemical composition:
| C% | S% | Cr% | Mo% | Cu% | Ni% | Mn% | P% | Al | Ti |
| 0.06～0.12 | ≤0.80 | 20.～23.0 | 6.0～6.5 | 0.5～1.0 | 35.0～40.0 | ≤1.00 | ≤0.025 | 0.20～0.60 | 0.70～1.20 |
Note: when using arc furnace smelting omega (Al + Ti) is not greater than 1.55%, using arc furnace + electroslag smelting omega (Al + Ti) is not greater than 1.75%.
GH2132 applications:
GH2132 has been used in the manufacture of a variety of aircraft engine combustor flame tube, strength diffuser, rectifying plate, stabilizer, oil ring, torque adjustable nozzle shell, pipe joint, bushing, and airplane tail cover parts such as skin, put into batch production. In 550 ~ 800 temperature range after long-term use of hardening phenomenon, slightly decreased plasticity at room temperature. Above 1000 high temperature oxidation resistance of the nickel-based alloy slightly worse than similar purposes.
JW steel keeps more than 10,000 tons hot rolled and cold rolled GH2132 steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find hot rolled and cold rolled GH2132 steel supplier, hot rolled and cold rolled GH2132 steel manufacturer, hot rolled and cold rolled GH2132 steel exporter, please contact JW steel’s sales team. We will give you the hot rolled and cold rolled GH2132competitive price, hot rolled and cold rolled GH2132 good quality and best service from us.
Material used:
- Alloy 20
- Nickel 200, 201
- Monel 400. K-500
- Inconel 600, 601, 625, 718, 725, X-750, 751, 783
- Incoloy 800, 800H, 800HT, 825, 890, 901, 925, 926
- Hastelloy B, B-2, C-22, C-276
- Special Stainless Steel F309, F310, F347, F348, 904L
- Dual Phase Steel F44, F51, F52, F53, F55
- Precipitation Hardening Steel 15-5PH, 17-4PH, 17-7PH, 18-8MoPH
- Stainless Steel S30403, S30408, S30409, S31008, S31603, S31608, S31609, S31668, S31703, S32168, S34779,
S39042, S11306, S22253, S22053, S21953
- High temperature alloy GH600, GH3128, GH3030, GH2132, GH1140
