41Cr4 Scr440 5140 Alloy Steel Plate 10 - 140mm Cutting

Name: 41Cr4 Scr440 5140 Alloy Steel Plate 10 140mm Cutting
Brand: HBIS
Price: 1000 USD

41Cr4 Scr440 5140 Alloy Steel Plate 10 - 140mm Cutting Manufactures

Brand Name : HBIS

Model Number : 5140 41Cr4 Scr440

Certification : ISO

Place of Origin : China

MOQ : 2 Ton

Price : 1000 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 300 Ton/month

Delivery Time : 5 - 12 days

Packaging Details : packing by waterproof paper and pallets

Products : Alloy steel plate

Grade : 5140 41Cr4 Scr440

Thickness : 10 - 140mm

Width : 2200mm or cutting as request

length : cutting as request

Brand : HBIS

Cutting method : fire cutting

Standard : ASTM

Contact Now

41Cr4 Alloy Steel Plate Scr440 5140 Steel Plate 10 - 140mm Steel Plate Cutting

41Cr4 steel is a Chrome Manganese steel used in the manufacture of quenched and tempered bars where strength required is less than SAE 4140 steel bars.

It is also suitable for induction hardening with a minimum hardness of 52HRC.

The cold-upsettable steel 41Cr4 can be cold-formed with suitable tools with a low to medium rate of forming according to the usual forming methods on single-stage and multi-stage presses. It is used for normed screws and screws manufactured according to drawings of strength class 8.8 in the thick dimension range. Also used for high-strength parts manufactured according to drawings (eg. ball studs).

Competitive Advantage for 41Cr4 material steel plate :

Available in stock for immediate shipment
High strength,
High tenacity
Good hardenability
High resistance to thermal properties.
Competitive price

1. Supply Range of 41Cr4 steel

Round Bar: diameter 20mm – 300mm
Steel Plate and Steel Block: thickness 10-140mm x width 100-2200mm
10-120mm thickness 41Cr4 plate are available all the time in stock,
90-150mm thickness plate to be newly production in 8-10 days lead time.

Surface Finish: Black Surface, Milled Surface or Polished Surface as per given requirements

2. Relevant AISI 5140 Specification and Equivalent Steel Grades

Country	USA	German	Japan
Standard	ASTM/AISI A29	EN 10083-3	JIS G4053
Grades	5140	41Cr4	SCr440

3. ASTM 5140 Material Chemical Composition and Equivalent

Standard	Grade/Steel Number	C	Mn	P	S	Si	Cr	Ni
ASTM A29	5140	0.38-0.43	0.70-0.90	≤0.035	≤0.040	0.15-0.35	0.70-0.90	–
EN 10083-3	41Cr4 / 1.7035	0.38-0.45	0.60-0.90	≤0.025	≤0.035	≤0.40	0.90-1.20	–
JIS G4053	SCr440	0.38-0.43	0.60-0.90	≤0.030	≤0.030	0.15-0.35	0.90-1.20	≤0.25
